DESCRIPTION
PURE BALANCE AMPLIFIER, OUTSTANDING CLEAR SOUND & SUPPORTS HIGH-RESOLUTIONS FILES
Unlike other amplifiers, the SRM-007tll consists of a pure balance amplifier in which the XLR balance input does not have to pass through a transformer or inversion amplifier. It is the only system that makes it possible to listen to sound in the most ideal manner permitted by the balance system. The use of on-inductive coil resistance realises straightforward properties that take advantage of the fitted vacuum tubes and audio with outstanding quality and high level of clarity. STAX has ensured that SRM-007tll has put in great efforts into the circuit constants. Thus, it achieves a higher grade of reproductivity for SACD and other new generation audio formats.



SPECIALLY DESIGNED FOR STAX ‘EARSPEAKERS’, ULTRA THIN POLYMER FILM & XLR AND ALL ANALOG VOICE INPUTS
The SRM-007tll has been exclusively designed for earspeakers characterized by their wide high dynamic range and outstanding operating features. Thus, pair your headphones with the SRM-007tll and enjoy the best that the world of music has to offer. Fitted with an ultra-thin polymer film, the SRM-007tll, lets you listen to music with an unprecedented response and a high degree of resolution. Experience your music in its most natural form. The high-quality sound quadruple volume unit makes it possible for XLR input as well as all kinds of line-level analogue voice inputs.



SPECS
FREQUENCY RESPONSE | DC to 100,000Hz +0,-1.5dB w/ SR-007 or SR-404 |
HIGH HARMONIC DISTORTION | Max. 0.02% (with 1kHz, 100V r.m.s. ) |
GAIN | 54dB (x500) |
INPUT IMPEDANCE | 50Kohm, 50kohm x 2 during balance |
MAX. OUTPUT VOLATGE | 340V r.m.s. (1kHz) |
STANDARD BIAS VOLTAGE | PRO 580V x 2 |
POWER VOLTAGE FREQUENCY | 117V (50Hz / 60Hz) |
TYPE | Vacuum tube output stage Low noise dual FET input Class A operation, Pure balance DC amplifier configuration Earspeaker driver unit |
VACUUM TUBE | 4 (6FQ7 / 6CG7) |
RATED INPUT LEVEL | 200mV / 100V Outputs |
MAX. INPUT LEVEL | 30V r.m.s. at min. volume |
INPUT TERMINALS | 3 ( XLR x 1, RCA x 2) with 1 RCA parallel out |
POWER CONSUMPTION | 55W |
TEMPREATURE AND HUMIDITY | 0 to 35ºC / 90% max. without condensation |
COLOR | Silver |
DIMENSIONS | 7.7 (W) x 4.1 (H) x 16.5 (D) in |
WEIGHT | 10.4lbs |
BOX CONTENTS | 1. STAX SRM-007tII |
FAQs
WARRANTY AND MEDIA REVIEWS
1 Year Warranty
Don't sweat it, this STAX SRM-007tII comes with a 1 year warranty from STAX that covers manufacturing defects. All products featured on Headphone Zone are backed by an original manufacturer's warranty.
Read more about STAX's warranty in India.
'A high level of sound purity is achieved through the simple two-stage amplification circuit with low-noise FET input stage. I liked the sound of this amp. A sweet and delicate presentation'
Read More
